oh I was wondering where can I buy the scanline generator?

here’s a comparison between a scanline generator and 3sOE.
\Real scanlines vs capcom’s official filter

64

oh I know I have herd its pretty bad

toodles is working one as we speak that’s what this thread is for. Right now arcade forge has the slg3000 they are based in German so its a little pricey with the conversion rate but its nice from what i have heard

65

Nice, I’ll be the first customer

66

Hey, nice project ;)))

So go here if you don’t want to wait :wink:

Official Scanline Generator at ArcadeForge.de

http://www.arcadeforge.de/wp-content/uploads/2011/01/IMG_4750-293x300.jpg

http://www.arcadeforge.de/wp-content/uploads/2011/01/IMG_4740-300x200.jpg

67

Hey toodles
are you still thinking of doing a female SCART connector with LM chip for the sync lines, that connects to that VGA input like you mentioned earlier in the post, if so I will not mess with making one on my own also I not sure if you got all the info I posted about the scart/RGB stuff
http://www.jammaboards.com/arcade_manuals/GBS-8220_CGA_to_VGA_HD-Converter.pdf
http://members.optusnet.com.au/eviltim/gamescart/gamescart.htm
http://www.mmmonkey.co.uk/console/other/jrgb.htm
http://www.gamesx.com/wiki/doku.php?id=av:japanese_rgb-21
http://www.gamesx.com/wiki/doku.php?id=av:scart2rgb

68

I’m going to wait until I have mine in my hands to play with so I can check over the pinouts of the connectors I’m looking at. They aren’t shown in the manual you linked.

The nice this is that I have a couple of random SCART cables. I think I have a SCART for Xbox1, and a couple of PSX->JPG_RGB_21 cables. Those will bee handy for sure.

69

Hey Toodles: Should I just go ahead and start paying you an arbitrary fee every couple of months for coming up with such cool stuff? :wink:

70

Yes,

would be nice with some screw terminals and some additional audio jacks. Perhaps like this one

http://1.bp.blogspot.com/-LVIwwCakxIM/TiAicV1pgGI/AAAAAAAACww/-Nnjy9buoPA/s320/IMG_1199.JPG

http://3.bp.blogspot.com/-MD8sQiXJha4/TiAiTXpfktI/AAAAAAAACwg/ums9YjE2CMw/s320/IMG_1197.JPG

Available already at ArcadeForge

Finally you end then here.

Complete your stuff doing some male to male adapters
Don`t forget the PSU and the UpScaler. The upscaler looks nice with a good enclosure. :wink:

The complete DIY Kit with SLG, Sync Stripper and GBS-8220 Upscaler is already available at Arcadeforge.de

71

Yeah, but do you get free stickers? :wink:

72

no, but T-Shirts ;)))

[

](‘http://4.bp.blogspot.com/-_zk_XQnuy8Q/TnHF_pSGawI/AAAAAAAAC9M/vOWylPRhx78/s1600/290835_181591281911194_110572675679722_413405_781_o.jpg’)
Sizes : S, M, L

I can send the logo, perhaps to integrate in the new pcb :wink:

73

WOW do you have to blast the this post with all your pictures??

lets have a little respect here no one is blasting your post with their products your products are great and always recommend if someone is looking to purchase something now without waiting so please stop posting your pictures

74

I agree. bencao: we all know about your products, and they are awesome. Heck, the whole reason this thread exists is because of the SLG3000. But this is just a fun (and less expensive) option for people. I’ve looked at your kits, and they are ridiculously nice, but your DIY kit would cost me minimum $160, and that’s before adding in international shipping. If Toodles brings this guy in at ~$15, and a SCART -> VGA sync cleaner for ~$25, coupled with a scaler (which the same one you sell can be bought from Paradise Arcade Shop for $42 shipped), then I just saved a TON of cash.

75

Sure, I take into account your ideas and talked with Clayton. I can do a collective order and we save a lot cash for shipping.Ordering more pcs means also I can go down in price for the units.

76

I’m not sure who this response to may be toodles

Hey Toodles I received my scalier and I’m not sure if you still needed to know the 8 pin layout but its Gnd/Gnd/VS/HS/S/B/G/R

77

Is the S supposed to be a composite sync? Hrm.I’ll have to take a peek at it whenever mine arrives.

78

Fagin has it labeled like this

Wire the HSYNC of the header (grey) .

Wire the VSYNC of the header (yellow)

Wire the GROUND of the header (black

79

Hi everyone

Very interested to see some improvements being made to the cheapy scanline generator :slight_smile:

Toodles - if you want me to put a feature about it on my site when it’s ready, let me know!

Ta
Pete

80

Appreciated, but let me actually get it made and working first :slight_smile:
Proto pcbs aught to be here Tuesday.
