Hi everyone:

EDIT:
Jasen’s Custom will be the official source to get the front panel, I won’t sell them anymore.
This means it will be easier for everyone to get one:

As explain in the thread in Tech Talk, I’ve made two board for installing Brook products into Madcatz TE/SE stick.
Thread here:

There’ videos about each products.

Madcatz audio board for Brook PS4+
http://i.imgur.com/cM4iL6ol.jpg
http://i.imgur.com/cuDS2Lul.jpg

NOTE: THE KIT IS NOT COMPATIBLE WITH THE VS FIGHTING STICK. ONLY TE/SE

Kit contains:

  • a audio board
  • a 20cm JST harness
  • 2 screws

Quantity: 36/60pcs

Madcatz Front Panel for Brook UFB and PS4+
http://i.imgur.com/kJONA5Gl.jpg
http://i.imgur.com/2C2lHwal.jpg

New: The kit is now using harness for presoldered pinhead for LS/DP/RS.
http://i.imgur.com/Tjm4CLxm.jpghttp://i.imgur.com/QjCjhEmm.jpg

(Note: Can still choose the JST one if you ask)

This is the REV 2 of the board I’ve made last year.
Kit contains:

  • a front panel with:
    [list]
    [] LS/DP/RS switch
    [    ] Lock/Unlock Home/Turbo/Start/Select switch
    [] Players LEDs where old top turbo led where or on Players LEDs for SFxT layout. Colors order are Blue, Red, Green and Purple (purple is slightly less bright)
    [    ] Turbo Button + LED. LED colors is random from what I have in stock
    [/list]
  • Harness for Players LEDS, LS/DP/RS and Turbo Key/Turbo LEDs

Options on order:

  • LEDS Layout: either classic for TE/SE or layout for SFxT stick (above home button),
  • Want something else than turbo? I can adapt the harness for what you want,
  • Ask for different LEDs color.
  • You can choose a JST connector for LS/DP/RS

SOLD OUT!!!

Price:

Audio Board = 5$ USD plus shipping
Front Panel = 10$ USD plus shipping.
Front Panel + Audio = 13$ plus shipping.

Shipping

I’m based in Canada so all the order are sent from there. I’m assembling all the boards by hand so expect some delay.
Don’t yell at me for the price, blame Canada Post.

Exemple of shipping to the US for 1 kit:
No tracking: 7$
Tracking: 15$

Exemple of shipping to Europe (i.e. England or France) for 1 kit
No tracking: 7€
Tracking: 28€

I’m not refunding you if an untracked package is lost. It’s at your own risk. I had too much issue with paypal as a seller and some bullshit so now I’m clearly anouncing it.
I didn’t have any problem for now with USA and Canada, but international shipping is an other thing.
I strongly suggest you to make a bulk order if you are in Europe and use a tracked package. I’ll do my best to avoid customs but don’t be surprise if you have some.

Payement

Paypal. I’ll send you my address and the total amount in USD. Bulk orders will have of course a discount on shipping.

1 Like
2

Installing front panel

Cable harness are designed to be plugged with the UFB and PS4+ with connectors’ orientation:
http://i.imgur.com/vO65JZBl.jpg

or with 90° header (courtesy from ArcadeShock)

*/!\ If you have a different orientation it won’t work. /!*

If you have headpin connectors please plug in the correct orientation.

3

Note: I need phone number for international shipping. This is requiered by paypal.
Please update your paypal profile or PM me when ordering.
Thanks!

4

Interested in getting a Front panel + harness. PM me. Thanks

5

Bumpin the thread: The kist is now with presoldered pinhead for LS/DP/RS.

http://i.imgur.com/Tjm4CLxm.jpghttp://i.imgur.com/QjCjhEmm.jpg

You can still ask for the JST connector.

6

Sorry if this is an stupid question, but my knowledge of electronics is pretty basic.

If I buy the audio board and desolder the jack, can I solder any TRRS jack to the board, so I can use a panel mount jack ? I know it won’t fit on the board, but soldering with cables and using the proper order, it should do it, right?

7

You’ll need a TRRS jack with internal switches and specifically on the second ring for the Brook PS4+.

This ring is supposed to be the ground and “close” the audio circuit from the board (and set it to internal sound). If it’s “open” (not grounded) then the board understand there’s something plugged. That’s why Brook recommands to ground this pin if you’re not using their daughter board, or else you won’t have sound.

Most of electronic components stores call them “X conductors, Y contacts”. I’ve never found one with only a switch on the 2nd ring, so you’ll have to find one with switch on all the contacts something like “4 conductors, 7 contacts” (tip, ring1, ring2, sleeve, switches on tip, ring1 and ring2).

8

Thanks for the information, I think if I end using my own jack, I will just use a normal TRRS and add an On/Off button , it is imposibble to find any panel mount options that fits what you said.

9

Bump - we hit half of the batch for the Front Panel Kit.

I still have shitloads of audio boards.

10

Hey,

So I added the front panel board and most of it works fine.

However, the home button doesn’t. I used a 20-pin harness on the Brook UFB and connected the Home button wires up to the locking mechanism on top of the board. If I use one, will the other not work?

11

Sorry, I don’t get your installation. Can post a pic?

The Home button only use 1 wire. The other wire is the KGround for Start and Select. The Black should be the Home, the Red is for Keyground.
Try to link the home to the terminals screw first to test if it’s working.

12

I won’t be able to do this until Wednesday, but I did screw in the one wire to ground. I’ll try removing it and see what happens.

13

You have to link to Something like that:
http://i.imgur.com/XEfW447l.jpg

If you have link the home to the ground, well yes it won’t work.

The KGround is supposed to replace the ground on Start and Select. As I told you, this is only if you want the lock switch on start/select.
If not, just leave the Kground alone.

1 Like
14

Interested in the front panel pm me please

15

Also Interested in the front panel. PM me pls.

16

I have interest in this as well. PM sent.

17

Bumping the thread. Only 15 front panels left.

18

Hello @The_Real_Phoenix . Do you know if your audio board and front panel board are usable on the madcatz x360 brawlstick?

19

Yes they are.
But remember that like the TE, you’ll have increase the size of the audio hole to let the 3.5mm barel to fit in.

20

I am interested in turning my x360 brawl stick into a universal stick. Could you provide me the details on potentially ordering one from you? I am in the US. Also are you selling the Brook UFB as well?

Thanks.
